Compact series valve
The Kaseman Compact Series is specifically designed to be used in locations where precision airflow control is required and space is of a premium. The structural design that is shorter and lighter in length and weight.
Compact series valve maintains the feature of a venturi valve, which can compensate for changes in static pressure in less than a second and maintain an accuracy of 5% of the target airflow rate as long as the differential pressure across the valve is between 150 and 750 Pa. And does not require straight duct runs upstream or downstream.
​
Two options in succession,
-
KCV compact constant venturi air valve
-
KMV compact variable venturi air valve
Compact series valve
KCV
The KCV is ideal for room supply air and general exhaust application especially on pharmaceutical clean room or healthcare facilities.
Features & Benefits:
-
High turndown ratios up to 20:1, helps reduce energy costs.
-
Pressure-independent valve avoids rebalancing costs.
-
Mechanical design flexibility means valves do not require straight duct runs upstream or downstream.
KMV
The KMV, a perfect air terminal option for the VAV system by Kaseman, is used with a high-performance actuator, typically installed in laboratory applications where fume hoods are present, ensuring the safety of users at the fume hood.
Features & Benefits:
-
High turndown ratios up to 20:1, helps reduce energy costs.
-
Pressure-independent valve avoids rebalancing costs.
-
Mechanical design flexibility means valves do not require straight duct runs upstream or downstream.
-
Supports 0-10V direct control of the desired airflow requirements.
